Windlass Thermal Circuit Breaker Panel - 70Amp
Panel mounted, a waterproof breaker that works with DC systems up to 48 volts. This trip-free breaker is ideal for a windlass circuit.
Features:
- Works with DC systems up to 48 volts
- Clear, single lever operation
- Combines switching and circuit protection into a single device
- "Trip Free" design cannot be held "ON" during fault current condition
- Ignition protected
Technical Specifications:
- Circuit Breaker Class - Type III
- Circuit Breaker Type - Thermally responsive bi-metal blade
- Maximum Voltage - 48V DC
- Amperage - 70Amp
- Mounting - Panel Mount
- Weight: -.5lb (0.23 kg)
*Sold as an Individual
Specifications:
- Amperage: 100a
- Box Dimensions: 1"H x 4"W x 5"L WT: 0.4 lbs
